Blood plasma freezer MBPF-2A is used to maintain and preserve the plasma without affecting its original quality. The special design of plasma clamp, large heat exchange area makes this plasma freezer reliable. The colourful touch screen system software screen makes operations user friendly.
Request Quote
Core temperature
≤ (-30) ℃
Temperature control range
(-70) ℃ ~ 100 ℃
Temperature fluctuation range
± 0.5 ℃
Temperature Uniformity
≤ 2 ℃
Max. Refrigeration Capability Per Cycle
14400 ml (200 ml × 72)
Cooling time for the Empty Box
(-55) ℃ ≤ 20 min & (-70) ℃ ≤ 40 min
Number of the special Plasma bag clip
12 pcs
Total Power
≤ 7 kW
Power supply
380 V ± 10 %, 50 Hz
Freezing method
Once the freezer attains temperature of (-55) ℃, put the plasma inside the box. Core temperature of the plasma reaches (-30) ℃ after 60 minutes.
Refrigerating method
Air cooling double stage
Overall dimension (L × W × H)
950 × 940 × 1760 mm
Inside dimension (L × W × H)
450 × 500 × 1050 mm
Outdoor unit dimension
800 × 750 × 950 mm
Total weight
350 kg
Fast refrigeration speed with function to maintain constant temperature
Automatic defrost function to keep the cabinet dry
Automatic alarm function system
Air cooling double stage refrigeration method
Blood plasma freezer is a medical equipment used to freeze the plasma instantly. It has wide applications in blood banks, hospitals, clinical research, biotechnology industry and in military.
